Frame Mount LED Trough Light

  • Made to measure
  • Designed to mount directly onto a frame or panel.
  • IP67 rated LED strip
  • 24 volt, 12w per metre
  • Available in Cool White and Warm White
  • Delivery:- 3-5 days Black or White, 10-14 days for special colours.

more info...

£0.00 ex VAT (each)

Have this product with its options and price emailed to you as a quote.

High-bright - Frame Mount

High-bright is almost the brightest Trough Light available in the UK, -  at 1440 Lumens per metre.

We use only the highest quality components, all of which are rated IP65 (or higher) against the weather, which allows us to give a 2 year RTB warrenty.

We also offer a choice of LED colour, Cool White (the most popular) and Warm White for a softer hue.

Length of LED Trough

We manufacture all our Trough Down Lights specifically to your required length.

Please Note:- Any length 3m or over may come in 2 sections and due to carrier constraints, any length over 5m will always be supplied in 2 or more sections.

LED Colour  -  Available in Cool and Warm White.

Troughlight Colour  -  Black or White are standard colours, - Red, Blue, Silver, Green & Yellow and other standard 4 digit RAL colours are available at an extra cost.

Cable Entry -  Left or right as you are facing the sign.

This Trough Down Light is designed to be directly mounted onto a frame or panel and requires no additional bracketry.

Photocell Switch - To automatically turn it on at sunset and off at sunrise, we offer a built in (pre-wired) version and a seperate wall fixing option for you electrician to connect.


Delivery is generally 2-3 days for stock colours, but if you want to save some money or need it in a hurry, check out our SALE PAGE which usually has a stock of ready made troughs in an assortment of sizes. Click here

Light Strip: High Bright


  • Internally mounted inside the aluminium case
  • IP67 rated
  • Mean Well LPB-60-24 or equivalent
  • Input: 100-240v   2.2A  50/60Hz
  • Output: +24v   4.2A
  • Built in Photocel Switch:-
  • Internally mounted inside the aluminium case
  • Royce Thompson P12HE
  • 70 LUX
  • Input: 230v (+/- 10%  Load: 2x250w


  • More energy efficient
  • Lower maintenance cost
  • Consistant illumination
  • Get the cost back from HMRC
  • Low Carbon Footprint
 LED's/metre  60
 Watts/metre  12
 Voltage  24
 Chipset  3528
 IP rating  IP67
 Beam Angle  120deg
 Warm White  1260
 Cool White  1440

 Bracket Fix Plate Dimensions:

61 x 36mm portrait

LED Trough Lighting
