Traditional Header & Swing Sign Panel

Basic header only double sided Swing Sign panel

Delivery usually 3-5 days for black other colours 10-14 days

more info...

£0.00 ex VAT (each)




Maximum 4 characters






Compatible file extensions to upload: ai, eps, tiff, jpeg, jpg, pdf

PANEL PREVIEW

height
Width

Have this product with its options and price emailed to you as a quote.

Rectangular Panel - with a traditional top frame only.



This double sided Swing Sign has an old traditional look with heavy framing along the top only.

Historically, these signs were made from wooden planks with a heavy timber moulding. They would take some time to manufacture, and then days and days to properly paint & protect, making them expensive in the first place, and then they required constant maintenance.



We've brought it all up to date with our very own aluminium extrusion fitted to a 19mm thick panel, neither of which will rot, - thereby requiring little or no maintenance.

The benefits include:-

  • Made to measure  - (click the 'Technical' tab above for further info)
  • Virtually maintenance free



Colour choices:-

The standard (and quickest) is a white PVC panel with powder coated black framing.



We can have the framing powder coated to your requirements, which tends to add 7-10 days to delivery. (Please enter the RAL colour code when ordering)

We don't spray the panels 'in house', - but can happily get you a quote.

Construction



 Frame

The frame is an aluminium extrusion, which we have specifically designed for double sided signs and to be easily fabricated into several variations, including this header only option. It is strong and robust, and the ends are finished off with colour coded blanking plates.

Standard colour is black, but we gan have it powder coated to your requirements (adds 7-10 days to delivery)



Hanging Eyes

Most of our Projecting Brackets have eye centres at 410mm so that is our default measurement for the eyes, - but if you're ordering this panel for a pre-existing bracket you need to give us the exact Eye Centres measurement.

We include M8 hanging eyes which screw to internal 'nut plates' that can't be pulled out.

You may need to order a pair of Karabina Links if it's being fitted to a pre-existing bracket, but if it's going onto one of our brackets there is no need for them.



Panel

The panel is a 19mm thick white satin faced PVC which is grooved along the top to accept the framing, and has internal strengthening screws.

The exposed panel edges can either be left square, or it can be 'bull nosed' and we can shape the panel to your requirements, - (although this may require an additional charge - please send us your ideas)



Write Your Own Review
You're reviewing:Traditional Header & Swing Sign Panel

Shipping costs

  • Delivery charges vary based on the product, size and delivery address.
  • Estimated delivery charges for this item.
    Mainland UK and Scottish Mainland - £15.95
    Grampions - £15.95
    Isle of Wight - £19.95
    Scottish and other Islands - £38.00
    Scottish Highlands - £28.25
    Northern Ireland - £38.00
  • For an accurate delivery charge, please enter the delivery postcode in the cart or at the checkout.

Shipping processing time

  • All orders for stock items are generally processed within 1-2 days working days.
  • Orders for special colours or more bespoke items will take longer. We usually have these processed within 10 days working days, but it may take longer depending on the specifications.
  • If you have a particular delivery deadline, please call the office on 01524 841726 to discuss your needs.
  • If we are experiencing a high volume of orders, shipments may be delayed. Please allow additional time for your delivery. If there will be a significant delay in any shipment of your order, we will contact you via email or telephone.

Shipment Confirmation & Order Tracking

  • As soon as your order is packed & ready for the courier, we will email your invoice with the Carrier & Tracking Information.

Deliveries

  • All deliveries must be examined - before being signed for.
  • Any damage or shortage must be noted with your signature and to us within 24 hours, otherwise the carriers will deny responsibility, and we will be unable to make a claim on your behalf.
